Platinum Sectional, Gas, 36″, 4 Non-Clog Burners, 12″ Charbroiler, Standard Oven Base – Propane, 217000 Total BTUs

The Platinum Series provides professional performance that chefs and restaurateurs can depend on. Made with 100% Stainless Steel construction, the Platinum Series includes heavy-duty ranges, griddles, planchas, charbroilers, stock pot ranges, fryers, uniform hot tops, french tops, and broilers that can be combined for a 100% custom line-up to fit the needs of any high-volume operation.

Product Features

  • 36" wide sectional range with a standard oven base
  • 9"-1/4" deep front rail
  • Stainless steel front, sides, rear and exterior bottom
  • Fully insulated lining and burner box
  • 1"-1/4" front gas manifold and 1" rear gas connection
  • 5" high stainless steel flue riser
  • 24 " Open Top Features Four 35,000 BTU LP patented non-clog burners
  • Removable, welded steel top grates
  • Removable drip tray
  • 12" Charbroiler Features Two 14,000 BTU LP burners with one high/low control knob
  • Removable cast iron grates with adjustable front-to-back slope that flip over for either 1/8" or 1/4" grid width
  • 600°F even surface temperature on high setting
  • Stainless steel burner radiants
  • Removable drip tray
  • 45,000 BTU LP oven with standing pilot and thermostat range of 175°F to 550°F (79°C to 288°C). Porcelain enamel interior, measuring 14” high x 26” wide x 26.5” deep. Two racks with five-position side rails

Options & Accessories

"¢ External pressure regulator "¢ Front rail options: Cutouts in front rail for sauce pans "¢ 7"¢1/4" deep front rail (to match old style sectional) "¢ Square belly bar mounted on 7"¢1/4" deep front rail "¢ Casters (front two casters lock) "¢ Cable restraint kit (to restrict movement when on casters) "¢ 24" or 36" high flue riser "¢ Shelves on flue riser (one on 24" flue riser, one or two on 36" flue riser, 10" deep, shelves not available above charbroilers) "¢ Tray or tubular shelving (shelves not available above charbroilers, 12" deep) "¢ Open"¢frame base with casters for battery "¢ Extra"¢deep rear"¢extending flue riser "¢ Stainless steel oven interior "¢ Salamander or cheesemelter mounted on 36" high flue riser "¢ Removable shelf inside cabinet "¢ Grooved griddle surface (Griddle Only) "¢ Chrome griddle surface (Griddle Only) "¢ Plated fish grids (Charbroiler only) "¢ Additional top configurations available. Contact factory for details "¢ Removable, cast iron grate tops "¢ Electronic oven pilot ignition (no charge) "¢ Battery spark ignition for open tops
